520-540 Watt Solar Panel_Guangzhou NOMO New Energy Co., Ltd.

SES-Solar-520~540Watt

520-540 Watt Solar Panel

Polycrystalline Module

APPLICATIONS

1) PID RESISTANT : Limited power degradation of Eagle module caused by PID effect is guaranteed under strict testing condition (85℃/85%RH,96hours) for mass production;

2) High Power Output : With up to 280 Wp and 17.11% efficiency , highest performing module of its kind on the market;

3) Low-light Performance : Excellent performance in low-light environments;

4) Severe Weather Resiliencen : Extremely weather resistant due to approval for increased snow and wind loads:5400 Pa snow load,2400 Pa wind load;

5) 4 Busbar Solar Cell : No power loss thanks to improved temperature co-effcient caused by 5 busbar solar cell.

6) positive power tolerance (0~+5W) guaranteed ; IEC 61215,IEC61730,UL 61730.ISO9001:2015:ISO Quality Management Sytsem ; ISO14001:2015 : ISO Environment Management System;Ts62941 : Guideline for module design qualification and type approval.OHSAS 18001:2007 Occupational Health and Safety.

Inquiry now

PRODUCT DETAIL

APPLICATION

There are many practical applications for the use of solar panels or photovoltaics. It can first be used in agriculture as a power source for irrigation. In health care solar panels can be used to refrigerate medical supplies. It can also be used for infrastructure. PV modules are used in photovoltaic systems and include a large variety of electric devices:

•Photovoltaic power stations

•Rooftop solar PV systems

•Standalone PV systems

•Solar hybrid power systems

•Concentrated photovoltaics

•Solar planes

•Solar-powered water purification

•Solar-pumped lasers

•Solar vehicles

SPECIFICATION

TYPICAL ELECTRICAL CHARACTERISTICS		MECHANICAL CHARACTERISTICS
Maximum Power	520-540	Output Cable	4mm²,300mm in length,length can be customized
Power Tolerance	0~5 Watts	Type of Connector	Compatible type MC4
Vmp [Voltage at Max. Power, V]	40.47	Dimension: AxBxC	1908x1134x35 mm
Imp [Current at Max. Power, A]	12.85	Weight	24.5 kg
Voc [Open Circuit Voltage, V]	48.99	Cell Orientation	120(6*20)
Isc [Short Circuit Current, A]	13.53	Construction	Single Glass 3.2mm coated tempered glass
VDC [Max-System Voltage, V]	DC1500V(IEC/UL)	Junction Box	IP68
Module Efficiency [%]	20.13	Frame	Anodized aluminum alloy frame
No. of Bypass Diodes [pcs]	3	QUALIFICATION TEST PARAMETERS
Max. Series Fuse [A]	20A	Operating Temperature	-40℃ ~ +85℃
Temperature Coefficient of Pmax	-0.35%/℃	RearSide Max.Static Loading	2400Pa
Temperature Coefficient of Voc	-0.27%/D℃	TFrontSide Max.Static Loading	5400Pa
Temperature Coefficient of Isc	0.048%/℃	Hailstone Impact	25mm hailstone at the speed of 23m/s
Nominal Operating cell Temperature	45±2℃	Fire Rating	UL
@1000W/m²; 1.5AM and 25℃ cell temperature		PACKAGING CONFIGURATION
		Packaging Configuration	31 pcs/pallet 7
		Loading Capacity	744 pcs/40'HQ
